| Items | Specification | Unit | Remarks |
| Panel size | 27 | inch | |
| Backlight overall dimensions | 626.0 X 364.2 X 13.0(Typ.) | mm | 25.9mm(Max.) |
| Luminous area size | 599.5 X 337.9 | mm | |
| LED light strip double-sided light input (up/down) | Bilateral light intake (up/down) | | |
| LED driver | have | | |
| Backlight brightness | 20000±5% | cd/m² | |
| Backlight power | 66.0±5% | W | 24V/2.15A |
| Power supply connection base | PH 2.0-14Pin | | |
| Light sensing head shape | 40 X 15 X 15 | mm | |
| Light sensing line length (Typ.) mm | 800(Typ.) | mm | Customizable line length |
| Storage temperature | -20-80 | ℃ | |
| Working temperature | -20-80 | ℃ | |
| Backlight weight | 2.9±0.1 | Kg | |
